PEX Pipe For Underfloor Heating

Product name

PEX pipe for underfloor heating

Sizes available

 16×2.0mm, 20×2.0mm, 25×2.5m, 32×3.0mm

Max. pressure rating

PN8 bars

Max. Working temperature

95℃

Material used

PEX-b  (Silan Crosslinking PE-Xb pipe, crosslinking is ≥65%)

Colors available

Transparent, white, red, blue or as per request.

Standards follow to

ISO 15875, ASTM F876/877

Markings on the pipe

Customer’s logo can be stamped

Samples available

Sample available for small quantity.

Packing method

Be packed in coils with 50m/100m/200m/300m/500m. Each coil of pipe be in cartons

MOQ

Negotiable

Production lead time

7-10 days for a 20ft container, 15-20 days for a 40ft container

Warranty time

15 years for normal using

Payment term

T/T or LC at sight

FOB loading port

Ningbo or Shanghai China

Place of origin

Zhejiang, China

Standard: ISO 15875

Size

Outer Dia.

Inner  Dia.

Wall Thick

Packing Legth

(mm)

(mm)

(mm)

(mm)

(m/coil)

16×2.0

16

12

2.0

50/100/200/300/500

20×2.0

20

16

2.0

50/100/200

25×2.5

25

20

2.5

50/100

32×3.0

32

26

3.0

50/100

Standard: ASTM F876/877

Size

Packing Length

(inch)

(feet/coil)

1/4"

10000

3/8"

10000

1/2"

300/500/1000

3/4"

300/500/1000

1"

300/500/1000
