Hydraulic Hose End Fittings Hydraulic Compression Fittings

2018-11-14

Basic Info

  • Material: Medium Carbon Steel

  • Surface Treatment: Galvanized Sheet

  • Color: Yellow or Silver

  • Other Material: Ss or Brass

  • Mini Order: Ok

  • Custom: Ok

  • Delivery: Within 7 Days

  • Transport Package: Plastic Bags & Carton Box

  • Origin: Ningbo ,China

  • Standard: DIN, ANSI, GB, JIS

  • Connection: Female

  • Head Type: Hexagon

  • Surface: Smooth

  • Match Hose: Supply

  • OEM: Ok

  • Drawing: Accept

  • Trademark: SUNPLAST

  • Specification: 3/8 inch to 2 inch

  • HS Code: 7307990000

Product Description

Hydraulic hose end fittings hydraulic compression fittings

Parameter of the fitting:

  E HOSE BORE   DIMENSIONS
PART NO. THREAD E DN DASH TUBE O.D. C H S
20541-14-04 M14X1.5 6 04 6 1.1 28 19
20541-16-04 M16X1.5 6 04 8 1.5 28.3 22
20541-16-05 M16X1.5 8 05 8 1.5 28.9 22
20541-18-06 M18X1.5 10 06 10 2 29.6 24
20541-20-08 M20X1.5 12 08 12 2.5 32.8 27
20541-22-08 M22X1.5 12 08 14 2.5 33.2 27
20541-24-10 M24X1.5 16 10 16 2.5 35.9 30
20541-30-12 M30X2 20 12 20 3 42.4 36

Note: 1.For use with braided hoses. 2. If use with spiral hoses, hose fitting series number is 20542-xx-xx;


Supply other type fitting:
1. Metric Fitting:
Flat Seal Fitting, Multi-seal fitting, spherical seal fitting, 60° Cone seal fitting, 74° cone seal fitting, 24°cone O-ring L.T. Fitting, 24°cone O-ring H.T. Fitting, JIS 60° Cone Seal Fitting, Standpipe Fitting, Japan Metric Fitting etc;
2. British Pipe Adapter:
JIS BSP 60° Cone seal Adapter, BSPT Adapter, BSP multi-seal adapter, BSP flat Seal Adapter, BSP O-ring Seal Adapter;
3. American Pipe Adaptor:
SAE Code 62 Flange, SAE Code 61 Flange, NPT Adaptor, JIC 74°Cone Seal Adaptor, NPSM 60°Cone Seal Adaptor, ORFS Flat Seal Adaptor, SAE O-ring Seal Adaptor
4. Banjo Adaptor:
Metric Banjo Adaptor, BSP Banjo Adaptor
5. Staple-lok Adaptor
6. Double Ended Adaptor
7. Metric Transition Adaptor
8. British Transition Adaptor
9. American Transition Adaptor
10.Other Adaptor & Fitting

Other type ferrules:
Ferrule for EN853 1SN-SAE100R1AT hose
Ferrule for EN853 2SN-SAE 100 R2AT hose
Ferrule for SAE R7 hose
Ferrule for SAE R8 hose
Ferrule for SAE R14 hose (teflon hose)
Ferrule for EN856 4SP hose
Ferrule for EN856 4SH hose
Ferrule for Industrial Hose Assembly
